Microplate types | 96-well plate(U,V,or plat-bottom) | ||||
Wavelength | 405nm,450nm,492nm,630nm,4 free positions for additional filters | ||||
Wavelength accuracy | <2nm | ||||
Reading range | 0.000-4.000Abs | ||||
Measurement range | 0.000-3.000Abs | ||||
Light source | LED,>100.000hours | ||||
Measuring system | 8-channel optical system | ||||
Test mode | End-point,kinetic,Multi-wave analysis | ||||
Well Coincidence | ≤0.015A | ||||
Linearity | r>0.999 | ||||
Repeatability | <0.3% | ||||
Reading speed | 5s single wavelength,10s double wavelength | ||||
QC | West guard Multi-rule,automated QC alert | ||||
Self-Checking function | Self-checking and calibration function | ||||
CPU | High-speed CPU | ||||
Printer | External jet printer,multi-form patient report | ||||
Interface | RS232 interface,USB | ||||
Power supply | 220VAC 15% or 110VAC 15% 50-60HZ 100W | ||||
Weight | 13KG | ||||
Work environment | Temp 5℃-40℃,Humi≤85% | ||||
NO, | Model | net weight | gross waight | packing dimension(cm) | machine dimension(cm) | shippment volume |
1 | SK201 | 11KG | 14KG | 58.5*51*38.5 | 45*53*22(H) | 23KG |
2 | SK202 | 9.5KG | 11.5KG | 51*47*30 | 44*35*22(H) | 15KG |
